    Heat transfer fluid Current Position: home > Heat transfer fluid

    CAS No: 61788-32-7

    Product Description
    RFCTHERM-PHT350 is also called Partial Hydrogenated Terphenyl, the materials is mainly from the distillation residue of Biphenyl process, RFCTHERM-PHT350 is one proven fluid and the world’s most popular and customer satisfaction high temperature, liquid phase heat transfer fluid, In critical applications, RFCTHERM-PHT350 is the only choice.
    Users can expect many years of reliable, trouble-free operation, even when operating continuously at the recommended maximum temperature of 350℃, It is miscible and interchangeable with other similarly constituted Hydrogenated Terphenyl fluids, such as: Therminol-66 and Dowtherm HT.

    The Temperature Range for use
    Liquid: 0 to 350℃
    Applications
    It can be used in a wide variety of industries, such as:
    · Chemicals
    · PET production
    · Synthetic Fiber plants
    · Plastics
    · Biodiesel
    · Many other applications that require a high temperature heat transfer fluid.

    Production Capacity: 3800mt/year,

    Typical Properties

    Item
    Standard
    Appearance
    Clear Pale Yellow liquid
    Constituent
    Partial Hydrogenated Terphenyl
    Average Molecular Weight
    252
    Density(20) g/ml
    1.000-1.010
    Chroma(Pt-Co)
    ≤300
    Flash Point (ASTM D-92)
    ≥184
    Fire Point (ASTM D-92)
    212
    Auto-ignition Temperature (ASTM D-2155)
    ≥375
    Water %
    ≤150ppm
    Viscosity (40), mm2/s
    26-37
    Normal Boiling Point
    ≥359
    Boling Range 10%
    ≥348
    Boling Range 90%
    ≤392
    Maximum Film Tem
    375
    Pour Point( )
    ≥-25
    Expansion Coefficient(200)
    0.000819/
    S
    ≤5ppm
    CL
    ≤2ppm
    Acid Value(mg KOH/g)
    ≤0.01
